- Guaranteed Secure Payments on Every Order
- Refund if your item is not delivered or as described
- Buyer Protection after order confirmation
- Place of Origin: china
- Brand Name: guoqiang
- Model Number: GQ-450
1. Performance and structural characteristics
*Advanced dual frequency control, flexible to control the length of bag, saving time and film.
*Manual operation machine, convenient and quick parameter setting
*Fault self diagnosis function, clear failure display.
*The digital input of the high precision photoelectric tracking system, sealing and cutting more precise, .
*The independent PID temperature control, suitable for all kinds of packaging materials.
*The positioning stop function, non stick knives, do not waste film.
2. Packaging range
Applicable to the towel, facial tissue paper, medicine, Chicken rolls, noodles, fish, sausage,
popsicle, candy, cookies, fruit and other soft, strip or irregular goods packaging.
3. Technical Parameter
Model | GQ-450 |
Film width | Max. 450mm |
Bag making length | 65-250 or 120-430mm |
Bag making width | 50-220mm |
Production height | Max. 80mm |
Packing speed | 40-100bag/min |
Film roll diameter | Max. 320mm |
Power specification | 2.8Kw/220V, 50/60Hz |
Outside dimension | 4020×720×1320mm |
Gross weight | 700kg |
4. Neutral Equipments
Number | Name | Brand | Country |
1 | Touch sensitive screen | WEINVIEW/XIANKONG | TAIWAN/SHENZHEN |
2 | PLC | PANASONIC | |
3 | Solid state relay | YONGMING | |
4 | Intermediate state relay | OMRON | |
5 | Photoelectric eye | BAIDELI | |
6 | Power | MW | |
7 | Transducer | PANASONIC | |
8 | Control temperature | YATAI/OMRON | |
9 | Access switch | FOTEK |
